652 Double Tilt Heating Holder

The 652 Double Tilt Heating Holderis a furnace type holder that allows the direct observation of micro structural phase changes, nucleation, growth and dissolution processes.

Key Features
HotHinge™

Makes miniature, fatigue resistant, heater wire connections to a tilting, high temperature furnace
Furnace characteristics


Incorporates tantalum furnace for vacuum applications; provides high-temperature strength and resistance to solid state welding to most materials (including silicon)
Inconel furnace used for atmospheric applications
Specimens can be heated to 1000 ºC in less than a minute using less than 8 watts of power
Small mass ensures rapid response to changes in heater current
ToggleTilt™ beta drive mechanism

Robust operation with no mechanical binding of the specimen cradle at tilt limits
Maximum +/- 30º using TEM or Accutroller control
Hexring® clamping system

Gently and securely holds the specimen in place
Tilt ranges, temperature ranges and compatibility of specimen holders vary according to the TEM manufacturer, model, pole piece gap, and the presence of in-gap accessories. Please contact your local Gatan representative for more information.
