英国Nanobean NB5 电子束光刻机

型号：

Nanobeam

产地：

德国

产品详情

英国Nanobean NB5 电子束光刻机

具有良好的稳定性，平均正常运行时间超过93%



规格:

束流电压范围为: 20kV - 100kV

光刻胶的特征尺寸: <8nm (光刻精度)

500um区域拼接/叠加误差: 小于25nm

自动装载5卡盘气锁系统


NB5发展目标:

改进设计和组件以减少日常服务需求。

实现每年少于5%的机器故障停机时间。

提高性能

便于批量生产。

NB5系统将为进一步发展高偏转速度和进一步集成电子提供平台。


The nB4 is a generation ahead of the current competition and with its field-proven performance has gained acceptance in the market place. It has excellent stability and has demonstrated an average uptime of greater than 93%. NanoBeam now introduces the nB5 which has been developed to further reduce delivery times and service costs.



NB5 development aims:

Refine design and components to reduce routine service requirements.
Achieve a machine-fault-downtime of less than 5% annually.
Enhance performance
Facilitate volume production.
Specification:

Beam Voltage range        20kV - 100kV
Feature size on resist      <8nm
Stitching/overlay error    <25nm for 500um field
Automatic loading            5 chuck airlock system

The nB5 system will provide a platform for further development to high deflection speed and further integrated electronics.

注：该仪器未取得中华人民共和国医疗器械注册证，不可用于临床诊断或治疗等相关用途

售后服务承诺

免费上门安装：是

保修期：1年

是否可延长保修期：否

保内维修承诺：经确认质量问题，免费更换。

报修承诺：24小时内到达现场并开始维修

免费仪器保养：6个月一次。

免费培训：免费安装及技术培训

现场技术咨询：无
